Clean Room Single Door

Name: Clean Room Single Door
Brand: DOORWIN ENGINEERING
Price: 15000.0 INR
Availability: InStock

Price 15000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Clean Room Single Door Specification

Floor
Compatible with vinyl, epoxy, and other cleanroom floors

Application
Pharmaceutical, Hospitals, Laboratories, Food Industry, Electronic Clean Rooms

Condition
New

Frame Material
Aluminum or Stainless Steel

Type
Swing Single Door

Feature
Smooth surface, easy to clean, air-tight sealing, flush design, corrosion resistant

Door
Single-leaf, flush type, glass vision panel (optional)

Weight
Approx. 40-60 kg depending on size and material

Material
Powder coated galvanized steel / Stainless steel / Painted steel

Dimension (L*W*H)
900 mm x 2100 mm (standard single door size), customizable

Thickness
40 mm (standard), customizable up to 100 mm

Colour Options
Available in RAL shades

Gasket
Continuous EPDM gasket for air tightness

Mounting
Wall or panel mounted

Locking System
Mortise lock or custom key lock

Window
Double glazed vision panel (optional)

Hinge Type
Heavy duty SS ball bearing hinges

Finish
Smooth powder coated or brushed stainless steel

Handle Type
SS D-handle or lever handle

Fire Rating
Up to 60 minutes (optional)

Operation
Manual

Sound Insulation
Excellent noise reduction

Customization
Available as per customer requirements

Clean Room Single Door Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
1 Months

Main Domestic Market
All India

About Clean Room Single Door

Clean room doors are specially designed doors used in controlled environments where airborne particles, contamination, temperature, humidity, and pressure must be strictly regulated. These doors help maintain the cleanliness and integrity of clean rooms used in industries such as pharmaceuticals, biotechnology, electronics, hospitals, food processing, and laboratories.

Superior Hygiene and Safety

Designed for critical environments, this clean room door features a flush, seamless construction with rounded edges for minimal particle collection and enhanced cleanability. Materials are carefully chosen for their resistance to corrosion and contamination, making the door ideal for pharmaceuticals, hospitals, and food processing industries. Integrated vision panels maintain visibility without compromising the sterile barrier.

Customizable and Versatile Design

Whether you require a standard single-leaf design or specific dimensions, these doors are customizable in size (900 mm x 2100 mm standard or bespoke) and thickness (40 mm standard, up to 100 mm). Options for surface finish, glass thickness, mounting method, and color ensure that each installation fits precisely with the intended cleanroom application. Door hardware and accessories can also be tailored to ensure the right fit and functionality.

Dependable Performance and Compliance

The door delivers air-tight sealing through EPDM or silicone gaskets and supports sound damping due to its robust sandwich construction. Fire resistance ratings and strong mechanical hardware (like SS lever handles or panic bars) address both safety and operational requirements. Each design aligns with industry standards for cleanrooms, helping ensure compliance and reliability in demanding environments.

FAQ's of Clean Room Single Door:

Q: How does the Clean Room Single Door ensure an airtight environment?

A: The door features EPDM or silicone gaskets around its edges, creating a highly effective seal that prevents air leakage. This helps maintain strict environmental control and minimizes particulate ingress, which is essential in cleanrooms and sterile areas.

Q: What customization options are available for this clean room door?

A: You can select from a range of finishes including powder-coated steel, SS 304/316, or customized colors. Glass panel thickness, overall door size, edge profiles, handles, locks, and accessories such as door closers or kick plates can all be tailored to your project's requirements.

Q: When should I opt for the double glass vision panel option?

A: The double glass vision panel is recommended when enhanced thermal or acoustic insulation is needed, or additional safety is a priority. Both 4 mm and 6 mm toughened glass options are available based on your application's sensitivity and visibility requirements.

Q: Where can this clean room door be installed?

A: Designed for high-standards of hygiene and containment, the door is suitable for installation in pharmaceutical facilities, hospitals, laboratories, food industry premises, electronic clean rooms, and similar controlled environments. It can be mounted on modular panels or brick walls.

Q: What benefits does the sandwich construction provide?

A: The sandwich panel structure not only adds rigidity and durability but also provides excellent sound damping, enhancing comfort and reducing noise levels within the cleanroom premises. It also accommodates various thickness requirements for further optimization.

Q: How is the surface cleanliness maintained?

A: The door's surfaces are anti-static and non-shedding, meaning they do not attract or release particles. The seamless, rounded-edge design simplifies cleaning, helping you maintain stringent hygiene standards with ease.

Q: What is the process for ordering a customized door?

A: First, specify your requirements regarding size, finish, accessories, and application. The manufacturer will then provide technical drawings and options for approval. Once confirmed, the door is fabricated to your exact specifications and delivered ready for installation.
